Product Name:

Chengliwei CLW5048TQZC6 tow truck

Dimensions:

5995×2300,2500,2400×2230,2280,2750,2300,2320,2350,2500,2400(mm)

Emission standard:

National VI

Cargo box size:

××(mm)

Gross Vechile Weight (GVW):

4495(Kg)

Approach/departure angle:

14/20,14/21(°)

Rated Payload:

1500(Kg)

Front/ rear overhang:

1150/1545,1115/1280(mm)

Curb weight:

2865,2800(Kg)

Maximum speed:

110(km/h)

Chassis Parameters

Fuel type:

Diese

Chassis model:

CA1043P40K50L2BE6A84

Number of axles:

2

Front wheel tread:

1520,1580,1601,1660(mm)

Wheelbase:

3300,3600(mm)

Rear wheel tread:

1475,1525,1590,1640,1740(mm)

Number of passengers in the cab:

(people)

Number of springs:

3/7+3,3/3+1,3/3+2,5/7+6,3/4+3,3/3,3/7+9,1/1+1,2/2+1,2/3+2,7/10+4

Number of tires:

6(pcs)

Axle load:

1950/2545

Tire specifications:

7.00R16 8PR,7.00R16 10PR,7.00R16LT 8PR,7.00R16LT   10PR,6.50R16LT 10PR,6.50R16LT 12PR

Engine Parameters

Engine Model:

Engine Manufacturer

Displacement(ml)

Power(kw)/horsepower(PS):

CA4DB1-11E6

China First Automobile Group Co.,   Ltd.

2207

81/110

CA4DB1-13E6

China   First Automobile Group Co., Ltd.

2207

95/129

Q23-132E60

Anhui Quanchai Power Co., Ltd.

2300

97/131

CA4DB1A13E6

China   First Automobile Group Co., Ltd.

2207

95.2/129

CA4DB1A14E68

China First Automobile Group Co.,   Ltd.

2207

100/136

D20TCIF62

Kunming   Yunnei Power Co., Ltd.

1999

103/140

F2.5NS6B160L

Beijing Foton Cummins Engine Co.,   Ltd.

2498

115/156

WP2.5NQ160E61

Weichai   Power Co., Ltd.

2490

118/160

CA4DB2-16E68

China First Automobile Group Co.,   Ltd.

2440

118/160

490PLUS2

Kunming Yunnei Power Co., Ltd.

2499

101/137

F2.5NS6B172

Beijing Foton Cummins Engine Co.,   Ltd.

2498

120/163

WP2.3NQ130E61

Weichai Power Co., Ltd.

2289

96/130

YN25PLUS160B

Kunming Yunnei Power Co., Ltd.

2499

114/155

CA4DB1-15E68

China First Automobile Group Co.,   Ltd.

2207

112/152

Other:

The vehicle is mainly used for road clearance, and the   special equipment is a flat mechanism and a winch. The vehicle has no towing   function. Side protection device material: Q235A carbon steel, connection   method: welding connection, rear protection device material: Q235A carbon   steel. Connection method: welding connection. Rear protection section size   (mm): 100×50,   rear protection ground clearance (mm): 400. ABS manufacturer/model: Zhejiang   Wanan Technology Co., Ltd./VIE ABS-II. Optional flip plate style, optional   integrated plate style. Accessories weight corresponding to curb weight:   fuel, lubricant, on-board tools. Curb weight (kg) 2865 corresponds to 2   quasi-passengers, and curb weight (kg) 2800 corresponds to 3   quasi-passengers. The corresponding relationship of vehicle   length/wheelbase/front overhang/rear overhang (mm) is: 5995/3300/1150/1545,   5995/3600/1115/1280. Optional side protection device style, optional side   protection is connected by bolts. Optional cab with chassis. Optional   telescopic plate style, optional flip plate style, optional integrated plate   style, optional panel without holes style. Optional rear taillight style.   Optional fuel tank, urea tank, battery installation position. Optional intake   duct style with chassis. Optional different appearance styles.
