Refrigerator Truck
CLW5042XLCCDP
  • Dimensions:
    5995×2260×3360(mm)
  • Engine:
    D25TCIF1/110KW
  • Loading Capacity:
CLW5042XLCCDP
  • Product FEATURE
  • PARAMETERS
  • CONSTRUCTION CASES
PRODUCT FEATURE
PARAMETERS
Main technical parameters of Chengliwei CLW5042XLCCDP refrigerated truck
Product Name:Chengliwei CLW5042XLCCDP refrigerated truckDimensions:5995×2260×3360(mm)
Emission standard:National VICargo box size:4050×2100×2200(mm)
Gross Vechile Weight (GVW):4495(Kg)Approach/departure angle:22/19,24/16(°)
Rated Payload:1100,1165(Kg)Front/ rear overhang:1120/1510,1120/1515,1110/1520,1110/1525,1015/1615,1015/1620(mm)
Curb weight:3200(Kg)Maximum speed:105(km/h)
Chassis Parameters
Fuel type:Diesel Chassis model:QL1049NBHAY
Number of axles:2Front wheel tread:1690,1640,1504(mm)
Wheelbase:3365,3360(mm)Rear wheel tread:1655,1425,1525(mm)
Number of passengers in the cab:(people)Number of springs:6/6+6,2/3+2,3/3+2,8/6+5
Number of tires:6(pcs)Axle load:1750/2745
Tire specifications:7.00R16LT 8PR
Engine Parameters
Engine Model:Engine ManufacturerDisplacement(ml)Power(kw)/horsepower(PS):
D25TCIF1Kunming Yunnei Power Co., Ltd.2499110/149
Other:
The top of the compartment is closed and cannot be opened; the ABS and its controller model is: CM4XL-4S/4M, the manufacturer is: Guangzhou Ruili Kemi Automotive Electronics Co., Ltd.; or the ABS and its controller model is: VIE ABS-Ⅱ, the manufacturer is: Zhejiang Wanan Technology Co., Ltd.; protective material: Q235A, the side protection and rear protection are bolted; the rear protection section size (mm): 100×50, ground clearance: 470mm; only the D25TCIF1 engine is selected, the fuel consumption value is: 10.90L/100km; the curb weight includes standard spare parts, excluding spare tires; the weight of the compartment is 880kg, the material of the compartment: the inner and outer skins are FRP fiberglass, the inner core is XPS extruded board, and the thickness of the compartment is 80mm; optional: direct power supply ETC on-board device, the power is equivalent to other models of refrigeration units, wheels, deflectors, side door positions, and internal styles;
