| Product Name | Brand Chengliwei Hook Loader Garbage Truck CLW5180ZXXC6 |
| Total mass (kg) | 18000 | Tank volume (m3) |
|
| Rated mass (kg) | 10085, 10150, 10395, 10460 | Dimensions (mm) | 8080,7780,7480,7280,7230×2480,2490×3190,2960,3031 |
| Curb weight (kg) | 7720, 7410 | Cargo size (mm) | XX |
| Number of passengers(person) | 3 | Maximum load of saddle (kg) |
|
| Approach/Departure Angle (°) | 17/24,17/24,17/24,17/24 | Front /rear suspension(mm) | 1400/1380,1400/1380,1400/1380,1400/1380,1400/1330 |
| Axle load(kg) | 6500/11500 | Maximum speed (km/h) | 89 |
| 【CHASSIS TECHNICAL PARAMETERS】 |
| Chassis model | CA1180P62K1L2A1E6Z | Chassis Name | Class II truck chassis |
| Chassis Brand | FAW | Manufacturer | China FAW Group Co., Ltd. |
| Number of Axles | 2 | Number of tires | 6 |
| Wheelbase(mm) | 5300,5000,4700,4500 | Tire specifications | 10.00R20,11.00R20,295/80R22.5,275/80R22.5 |
| Number of leaf springs | 10/12+8,12/12+8,13/12+8,7/7+6,9/12+8,12/10+9,7/7+3 | Front track(mm) | 1928, 1827, 1950, 1938 |
| Fuel type | Diesel Oil | Rear Track(mm) | 1878, 1860 |
| Emissions according to standards | GB17691-2018; Euro Ⅵ |
| Engine Model | Engine Manufacturer | Engine Displacement（ml) | Engine Power (kw/ps) |
| CA4DK1-18E6 | China FAW Group Co., Ltd. | 4764 | 139/189 |
| CA4DK1-22E6 | China FAW Group Co., Ltd. | 4764 | 165/224 |
| CA6DH1-22E6 | China FAW Group Co., Ltd. | 5700 | 165/224 |
| CA6DH1-24E6 | China FAW Group Co., Ltd. | 5700 | 179/243 |
| D6.7NS6B230 | Dongfeng Cummins Engine Co., Ltd. | 6700 | 169/229 |
