| Product Name | Brand Chengliwei Garbage Compactor Truck CLW5251ZYSE6 |
| Total mass (kg) | 25000 | Tank volume (m3) |
|
| Rated mass (kg) | 10025, 10090 | Dimensions (mm) | 10500,10300,10050X2520X3300 |
| Curb weight (kg) | 14780 | Cargo size (mm) | XX |
| Number of passengers(person) | 2, 3 | Maximum load of saddle (kg) |
|
| Approach/Departure Angle (°) | 25/20 | Front /rear suspension(mm) | 1450/3350, 1250/3350, 1450/3100, 1250/3100 |
| Axle load(kg) | 7000/18000 | Maximum speed (km/h) | 88 |
| 【CHASSIS TECHNICAL PARAMETERS】 |
|
|
|
| Chassis model | EQ1250GL6DJ | Chassis Name | Class II Cargo Truck Chassis |
| Chassis Brand | Dongfeng | Manufacturer | Dongfeng Motor Group Co., Ltd. |
| Number of Axles | 2 | Number of tires | 6 |
| Wheelbase(mm) | 4350+1350 | Tire specifications | 11.00R20 18PR |
| Number of leaf springs | 9/13,13/10,3/10 | Front track(mm) | 1910, 1970, 2020, 2050 |
| Fuel type | Diesel Oil | Rear Track(mm) | 1820/1820, 1860/1860 |
| Emissions according to standards | GB3847-2005,GB17691-2018; Euro Ⅵ |
| Engine Model | Engine Manufacturer | Engine Displacement | Engine Power |
| B6.2NS6B260 | Dongfeng Cummins Engine Co., Ltd. | 6200 | 191 |
| B6.2NS6B230 | Dongfeng Cummins Engine Co., Ltd. | 6200 | 169 |
| YCS06270-60 | Guangxi Yuchai Machinery Co., Ltd. | 6234 | 199 |
| YCK05240-60 | Guangxi Yuchai Machinery Co., Ltd. | 5132 | 176 |
| YCS06245-60A | Guangxi Yuchai Machinery Co., Ltd. | 6234 | 180 |
