| Product Name | Brand Chengliwei Garbage Compactor Truck CLW5040ZYS6 |
| Total mass (kg) | 4495 | Tank volume (m3) |
|
| Rated mass (kg) | 400 | Dimensions (mm) | 5995, 5745X2080X2400 |
| Curb weight (kg) | 3965 | Cargo size (mm) | XX |
| Number of passengers(person) | 2 | Maximum load of saddle (kg) |
|
| Approach/Departure Angle (°) | 27.7/14 | Front /rear suspension(mm) | 1055/1740 |
| Axle load(kg) | 1600/2895 | Maximum speed (km/h) | 110 |
| 【CHASSIS TECHNICAL PARAMETERS】 |
| Chassis model | EQ1045SJ3CDF | Chassis Name | Class II Cargo Truck Chassis |
| Chassis Brand | Dongfeng | Manufacturer | Dongfeng Motor Co.,Ltd. |
| Number of Axles | 2 | Number of tires | 6 |
| Wheelbase(mm) | 2700/2950/3308 | Tire specifications | 6.50R16,7.00R16,7.50R16LT 8PR |
| Number of leaf springs | 6/6+5,3/3+3,2/3+2,5/7+3, | Front track(mm) | 1525, 1519, 1472 |
| Fuel type | Diesel Oil | Rear Track(mm) | 1498, 1516, 1586,1458, 1650 |
| Emissions according to standards | GB17691-2018; Euro Ⅵ |
|
|
| Engine Model | Engine Manufacturer | Engine Displacement | Engine Power |
| D20TCIF1 | Kunming Yunnei Power Co., Ltd. | 1999 | 93 |
| Q23-115E60 | Anhui Quanchai Power Co., Ltd. | 2300 | 85 |
