| Product Name | Brand Chengliwei Garbage Compactor Truck CLW5250ZYSD6 |
| Total mass (kg) | 25000 | Tank volume (m3) |
|
| Rated mass (kg) | 10905, 10970, 11205, 11270 | Dimensions (mm) | 10280,9680X2550X3250 |
| Curb weight (kg) | 13900, 13600 | Cargo size (mm) | XX |
| Number of passengers(person) | 2, 3 | Maximum load of saddle (kg) |
|
| Approach/Departure Angle (°) | 20/11 | Front /rear suspension(mm) | 1500/3080, 1480/3080, 1500/2480, 1480/2480 |
| Axle load(kg) | 7000/18000 | Maximum speed (km/h) | 98 |
| 【CHASSIS TECHNICAL PARAMETERS】 |
| Chassis model | DFH1250D4 | Chassis Name | Class II Cargo Truck Chassis |
| Chassis Brand | Dongfeng | Manufacturer | Dongfeng Commercial Vehicle Co., Ltd. |
| Number of Axles | 2 | Number of tires | 6 |
| Wheelbase(mm) | 4350+1350 | Tire specifications | 295/80R22.5 18PR,11.00R20 18PR |
| Number of leaf springs | 3/10,3/4,9/10 | Front track(mm) | 2010, 2040, 2070 |
| Fuel type | Diesel Oil | Rear Track(mm) | 1860/1860, 1880/1880, |
| Emissions according to standards | GB3847-2005,GB17691-2018; Euro Ⅵ |
| Engine Model | Engine Manufacturer | Engine Displacement | Engine Power |
| D6.7NS6B290 | Dongfeng Cummins Engine Co., Ltd. | 6700 | 213 |
| DDi75E350-60 | Dongfeng Commercial Vehicle Co., Ltd. | 7500 | 257 |
| DDi75E300-60 | Dongfeng Commercial Vehicle Co., Ltd. | 7500 | 220 |
