| Product Name | Brand Chengliwei Garbage Compactor Truck CLW5070ZYSQ6 |
| Total mass (kg) | 7300 | Tank volume (m3) |
|
| Rated mass (kg) | 1,870 | Dimensions (mm) | 6650X2050X2750 |
| Curb weight (kg) | 5300 | Cargo size (mm) | XX |
| Number of passengers(person) | 2 | Maximum load of saddle (kg) |
|
| Approach/Departure Angle (°) | 24/15 | Front /rear suspension(mm) | 1015/2045 |
| Axle load(kg) | 2580/4720 | Maximum speed (km/h) | 95 |
| 【CHASSIS TECHNICAL PARAMETERS】 |
| Chassis model | QL1070BUHACY | Chassis Name | Class II Cargo Truck Chassis |
| Chassis Brand | ISUZU | Manufacturer | Qingling Motor Co., Ltd. |
| Number of Axles | 2 | Number of tires | 6 |
| Wheelbase(mm) | 3360 | Tire specifications | 7.00R16LT 14PR,7.00-16LT 14PR |
| Number of leaf springs | 8/6+5 | Front track(mm) | 1,504 |
| Fuel type | Diesel Oil | Rear Track(mm) | 1425 |
| Emissions according to standards | GB3847-2005,GB17691-2018; Euro Ⅵ |
| Engine Model | Engine Manufacturer | Engine Displacement | Engine Power |
| 4KH1CN6LB | Isuzu (China) Engine Co., Ltd. | 2999 | 88 |
