Number of axles:Number of tires:
| Main technical parameters of Chengli CL5041GJY6BWG fuel truck | |||
|---|---|---|---|
| Product Name: | Chengli CL5041GJY6BWG fuel truck | Dimensions: | 5400×1890×2350(mm) |
| Emission standard: | National VI | Cargo box size: | ××(mm) |
| Gross Vechile Weight (GVW): | 4495(Kg) | Approach/departure angle: | 20/14(°) |
| Rated Payload: | 1470(Kg) | Front/ rear overhang: | 1130/1420(mm) |
| Curb weight: | 2895(Kg) | Maximum speed: | 80(km/h) |
| Chassis Parameters | |||
| Fuel type: | Diesel | Chassis model: | BJ1045V9JB5-54 |
| 2 | Front wheel tread: | 1495,1510(mm) | |
| Wheelbase: | 2850(mm) | Rear wheel tread: | 1435,1455(mm) |
| Number of passengers in the cab: | (people) | Number of springs: | 7/7+5,7/4+3,7/5+2,3/5+2,2/3+2,3/3+3 |
| 6(pcs) | Axle load: | 1800/2695 | |
| Tire specifications: | 6.50R16LT 10PR,195/75R16 10PR | ||
| Engine Parameters | |||
| Engine Model: | Engine Manufacturer | Displacement(ml) | Power(kw)/horsepower(PS): |
| Q23-115C60 | Anhui Quanchai Power Co., Ltd. | 2300 | 85/115 |
| Q23-115E60 | Anhui Quanchai Power Co., Ltd. | 2300 | 85/115 |
| Q23-132E60 | Anhui Quanchai Power Co., Ltd. | 2300 | 97/131 |
| Q25A-150E60 | Anhui Quanchai Power Co., Ltd. | 2496 | 110/149 |
| Other： | |||
| The ABS system control mode is 4S/4M, air brake: ABS model is CM4XL-4S/4M, the manufacturer is Guangzhou Ruili Komi Automotive Electronics Co., Ltd. Liquid brake: ABS model is CM4YL, the manufacturer is Guangzhou Ruili Komi Automotive Electronics Co., Ltd. Liquid brake: ABS model is CM0953YL, the manufacturer is Guangzhou Ruili Komi Automotive Electronics Co., Ltd. A speed limiter is installed; speed limiter speed (km/h): 80; maximum density of transportable medium: 700 kg/cubic meter. Total capacity of the tank: 2.2 cubic meters, effective volume of the tank: 2.1 cubic meters. Overall dimensions of the tank (length × major axis × minor axis) (mm): 2900 × 1250 × 850. The curb weight includes on-board tools, spare tire, and fire extinguisher. Models and manufacturers of refueling machines that can be equipped: BL1111Z/Zhuhai Beilin Refueling Equipment Co., Ltd. Zhongshan Branch, HS1812B/Token Hengshan Technology (Guangzhou) Co., Ltd., SKES-1112/Henghe Jiahua Technology Co., Ltd., SKDS-2001A/Shanghai Bolai Machinery Co., Ltd., SK20QF-111A, SK20QF-222A/Zhengzhou Sanjin Petroleum Equipment Manufacturing Co., Ltd., CS20D1110F/Zhengxing Technology Co., Ltd., JSK-70B1121CZ, JSK-70B1121C, JSK45B1121C/Wen'en Jialijia (Beijing) Petrochemical Equipment Co., Ltd., HT- YV60E/Suizhou Huate Special Equipment Co., Ltd., XTST121BF1/Xingtai Zhengruntong Technology Development Co., Ltd., BL1211Z/Guangdong Beilin Energy Equipment Co., Ltd., FBXO(EX), ACZS-1112, ACZS-1111/Yongjia County Aocheng Hardware Products Co., Ltd., HT-CZ0111, HT-CZ1111/Hubei Huate Special Equipment Co., Ltd., ZH3111/Foshan Zhongze Electromechanical Technology Co., Ltd., ZY18111Z, ZY18111Y, ZY18222Z, ZY18222Y, ZY18424J, ZY18424Y/Anhui Zhongyuan Instrument Co., Ltd. Connection method: The left and right side protection and the rear lower protection are both connected by bolts. Protective material: Q235B carbon steel, protective section size (mm): 100×50, rear lower protection ground clearance (mm): 380. Only chassis radial tires are used. The front wheels of the vehicle are equipped with disc brakes and front exhaust pipes. The vehicle is suitable for the transportation of dangerous goods. The type of transport vehicle: FL type. The steering wheel is equipped with a tire blowout emergency protection device. The vehicle can be equipped with an optional direct power supply ETC on-board device and a driving recorder with satellite positioning function. The corresponding relationship of vehicle length/wheelbase/front overhang/rear overhang (mm) is: 5400/2850/1130/1420. The cab is optional with the chassis. The tank top has no lifting guardrail. | |||
Announcement on road transport vehicle compliance
| Product Model | Qualified vehicle number | Product Name | Company Name | Details |
|---|---|---|---|---|
| CL5041GJY6BWG | Fuel truck | Chengli Automobile Group Co., Ltd. |
