| The vehicle is a dangerous goods transport vehicle with a closed and non-openable top. It transports goods packed in independent containers (bottles). Dangerous goods vehicle type: EX/Ⅱ type vehicle. Dangerous goods item number: 1.1B, 1.1G, 1.1D, 1.2D, 1.3C, 1.1C, 1.4G. ABS model/manufacturer 1 is: CM4XL-4S/4M/Guangzhou Ruili Komi Automotive Electronics Co., Ltd., ABS model/manufacturer 2 is: VIE ABS-Ⅱ/Zhejiang Wanan Technology Co., Ltd.; Speed limiter installed; Speed limiter (km/h): 80; A driving recorder with satellite positioning function installed; Material, connection method and main dimensional parameters of rear protection device (section size and ground clearance): Side and rear protection material: Q235, connection method: left and right side and rear lower protection are bolted, rear lower protection section size (mm): 100×45, rear lower protection ground clearance (mm): 420; Only chassis radial tires are used, the front wheel of the vehicle is equipped with disc brakes, front exhaust pipes, and tire blowout emergency protection devices are installed on the steering wheel. The safety device is an electrostatic conductive belt to prevent static electricity. Accessories corresponding to the curb weight: standard accessories, spare tire, fire extinguisher, cleaning fluid, coolant, and a full fuel tank. The cargo compartment weight is 1140kg, 940kg. Optional ETC vehicle-mounted device with direct power supply. The corresponding relationship between engine and fuel consumption (L/100km) is: WP2.3NQ130E61 (10.83), HFC4DE3-2E5 (9.91). The optional side of the box does not open the door. The optional cab is installed with the chassis. Box material/thickness: composite board structure box: the bottom plate material is Q235, the thickness is 3mm, the side plate is Q235 outside + middle flame retardant foam + inner pure aluminum plate, the thickness is 42mm. The number, size and position of the door type on the side of the box are optional. The front face, urea tank, battery, and post-processing installation position are optional with the chassis. The optional auxiliary mirror bar is optional with the chassis, and the aluminum alloy rims and wheels are optional, and the front panel logos of different styles are optional. |
