Basic technical parameters of the vehicle | ||
1 | Model | CL5042XJH6YS |
2 | Chassis Brand | Ford V348 , JX6581TA-M6 |
3 | Dimension（mm） | 5780×1974×2690 mm |
4 | Medicine Cabin Size | 3125*1750*1850mm |
5 | GVW（kg） | 3700 |
6 | Curb Weight（kg） | 2750 |
7 | Engine Model | DURATORQ4D226H |
8 | Engine Type | In-line four-cylinder, supercharged and intercooled, high pressure common rail |
9 | Fuel Type | Diesel |
10 | Displacement (ml) | 2198 |
11 | Emission Standard | Euro VI |
12 | Maximum power | 103kw |
13 | Fuel Tank（L） | 80 |
14 | Wheelbase (mm) | 3750 |
15 | Suspension System | Front suspension McPherson independent suspension Rear suspension leaf spring non-independent suspension |
16 | Braking System | Front ventilated disc type Rear solid disc type |
17 | Gearbox | 6 forward gears, 1 reverse gear |
18 | Maximum speed (km/h) | 145 |
19 | Rated passenger capacity (person) | 6-9 |
20 | Tire | 215/75R16LT , 4pcs |
21 | Number of leaf spring | -/2 |
22 | Wheel base (front/rear) (mm) | 1740/1704 |
23 | Approach / departure angle | 22/24 |
24 | Front suspension/rear suspension (mm) | 933/1097 |
Vehicle standard configuration | ||
25 | ABS brake system | |
26 | Central control door lock | |
27 | Cab electric doors and windows | |
28 | Driver's seat airbag | |
29 | remote key | |
30 | Cab cooling and heating system | |
31 | Reversing radar | |
32 | Same color bumper | |
33 | Three seats in the cab | |
34 | USB | |
35 | The rear door double open 180 degrees open | |
36 | Foot pedals for rear and side doors | |
Air conditioning and Lighting system | ||
1 | Original cab system | |
