| EBS model/manufacturer: EBS5/Dongke Knoll Commercial Vehicle Braking System (Shiyan) Co., Ltd.; VIE EBS/ESC-Ⅱ/Zhejiang Wanan Technology Co., Ltd. Installed with speed limiter; speed limiter (km/h): 80; installed with a driving recorder with satellite positioning function; engine/fuel consumption value (L/100km) corresponding relationship: DDi75E350-60 (38.1), L9NS6B400 (38.2). Protection material: aluminum alloy, connection method: left and right side protection and rear lower protection are bolted, rear protection section size (mm): 120×60, rear protection ground clearance (mm): 480; maximum density of transport medium: 830 kg/m3. Total capacity of tank: 25.5 m3, effective volume of tank: 24.36 m3. Tank dimensions (length × major axis × minor axis (mm): 8800 × 2300 × 1600; Dangerous goods transport vehicle type: FL type; Other instructions: This vehicle is suitable for dangerous goods transportation. Only chassis with radial tires is used. The front wheels of the vehicle are equipped with disc brakes, front exhaust pipes, and tire blowout emergency protection devices are installed on the steering wheels. The rear axle of the vehicle adopts air suspension. The cab is optional with the chassis. The corresponding relationship of vehicle length/wheelbase/front overhang/rear overhang is (mm): 11600/1995+4500+1350/1480/2275. This model is equipped with an optional ETC vehicle-mounted device. Optional tool box position. Optional post-processor style. |
