Serial number | Item | Model and specification |
1 | Brand | Chengli Wei |
2 | Model | CLW5110JGKD6 |
3 | Chassis brand/model | Dongfeng/ EQ1185LJ9CDE |
4 | Dimension | 10100×2500×3800mm |
5 | GVW | 10995kg |
6 | Curb Weight | 10800kg |
7 | Wheelbase | 4500mm |
8 | Engine | YCS04200-68 / 147kw/200hp/ EURO VI |
Upper Structure configuration | Scope of work | Maximum operating height of 22 meters (including one person's height of 1.7 meters) The height of the platform from the ground≥20.3m Maximum operating range of the platform≥9.67m Operating range at the maximum operating height of the platform≥3.15m Operating height when the platform's maximum operating range is ≥12.3m |
Working bucket | Rated load of working bucket 200kg Working bucket size: 1200*610*1100cm | |
Outrigger | Method: H-shaped outrigger Quantity: 4 Control: Individually adjustable or linked. Transverse span: 2930mm Longitudinal cross play: 5200mm | |
Hook | Safe lifting weight≤800kg, max lifting weight 1000kg Maximum lifting height 8.5m | |
operating system | Equipped with two operating systems, the upper and lower operating systems can complete the lifting and rotating actions on the turntable and the working bucket. Control form: electro-hydraulic control. | |
Hoarding and platform board | Steel tool box and hoarding, pattern anti-skid platform | |
Boom structure | Three-section folding arm | |
Boom material | Q345B alloy structural steel | |
Balance device | External balance rod | |
Slewing device | Two-way 360 degree continuous rotation | |
safety equipment | The outrigger cylinder is equipped with a hydraulic lock, and the working arm cylinder is equipped with a two-way balance valve. |
