Serial number | Item | Model and specification |
1 | Brand | Chengli Wei |
2 | Model | CLW5060JGKD6 |
3 | Chassis brand/model | EQ1075DJ3CDF |
4 | Dimension | 7400×2000×3100 |
5 | GVW | 5520 |
6 | Curb Weight | 5195 |
7 | Wheelbase | 3308mm |
8 | Engine | H20-120E60 / 90kw 122hp |
Upper Structure configuration | Scope of work | Maximum operating height of 16 meters (including one person's height of 1.7 meters) The height of the platform from the ground≥14.3m Maximum operating range of the platform≥6.92m Operating range at the maximum operating height of the platform≥2.26m Operating height when the platform's maximum operating range is ≥9.2m |
Working bucket | Rated load of working bucket 200kg Working bucket size: 1200*600*1100cm | |
Outrigger | Method: H-shaped outrigger Quantity: 4 Control: Individually adjustable or linked. Transverse span: 2680mm Longitudinal cross play: 3050mm | |
Hook | Safe lifting weight≤900kg. Maximum lifting height 7.2m | |
operating system | Equipped with two operating systems, the upper and lower operating systems can complete the lifting and rotating actions on the turntable and the working bucket. Control form: electro-hydraulic control. | |
Hoarding and platform board | Steel tool box and hoarding, pattern anti-skid platform | |
Boom structure | Three-section folding arm | |
Boom material | Q345B alloy structural steel | |
Balance device | External balance rod | |
Slewing device | Two-way 360 degree continuous rotation | |
safety equipment | The outrigger cylinder is equipped with a hydraulic lock, and the working arm cylinder is equipped with a two-way balance valve. |
